Elac :  Navis ARB-51 (Black Highgloss) + IFI Zen Stream

The Navis Powered Bookshelf Speaker

ELAC’s new Navis Series answers every minimalist audiophile’s dream of a no-compromise powered speaker driven by best-inclass amplifiers that are truly deserving of the name “high end.” While most powered speakers rely on Class D digital designs, ELAC engineers build in 300 watts of pure analog amplification— for maximum power and exceptional sound. Add the Discovery Connect wireless transmitter to your system, and Navis becomes a wireless speaker that lets you enjoy streaming content without a cable in sight.

---

Custom-Designed Midrange/Tweeter

One reason the Navis sounds so natural is because of its in-house developed transducer, a 4-inch aluminum midrange driver with a concentrically mounted 1-inch soft-dome tweeter. Combined, this signature configuration lets Navis set the performance standard for its class.

---

Custom-Designed Woofer

Navis’s single woofer reproduces bass with authority, thanks to the special design of its driver. Developed in-house, the 5¼-inch aluminum cone is the ideal structural material, speci-fied for its ability to deliver slam, punch and accurate low-fre-quency fundamentals.

---

Beautiful Cabinets

Navis’s elegant design integrates perfectly with any interior. Its enclosure has a fine-furniture finish, available in Gloss Black, Gloss White and Wood Veneer. A dedicated floor stand completes the installation, and is recommended for optimum performance.

---

Powerful Trifecta

Inside each Navis Bookshelf Loudspeak-er is a Tri-Amp Pure Analog Amplifier, employing three separate amps for each transducer: a 160-watt BASH AB ampli-fier for the woofer, a 100-watt BASH AB amplifier for the midrange, and a 40-watt Class AB amplifier for the tweeter. A total amplifier power of 300 watts ensures that each transducer is optimally—and am-ply—powered, eliminating clipping and crossover distortion, and driving each transducer  with authority. Specs like a 110 dBA signal-to-noise ratio and 100 uV noise floor could only come from such audiophile-quality amps!

---

Flexible Connections

Local inputs include balanced XLR, RCA and Wireless, when used with ELAC’s Discovery Connect wireless transmitter to stream Discovery, Spotify Connect, Bluetooth, AirPlay and Roon. Just switch Wireless “Off” for a no-compromise analog input and output.

---

Specifications

Speaker type	3-Way Powered
Tweeter:	1" Soft Dome Concentrically Mounted
Midrange...	4" Aluminum
Woofer:	5-1/4" Aluminum
Frequency Response:	44 Hz - 28 kHz
Crossover Frequency.	2.2kHz / 260Hz
Total Amplifier Power	300 Watts Total
Bass Amplifier	160 Watt Bash Amplifier
Midrange Amplifier	100 Watt Bash Amplifier
Tweeter Amplifier	40 Watt Class AB Amplifier
Inputs	RCA / XLR / AirX² Wireless
Height	13.58"
Width	7.44"
Depth	9.45"
Net weight (each)	17.85 lbs
